Rows: 11
Use the filters above each column to filter and limit table data. Advanced searches can be performed by using the following operators:
<, <=, >, >=, =, *, !, {, }, ||,&&, [empty], [nonempty], rgx:
Learn more

TableFilter v0.0.9

http://koalyptus.github.io/TableFilter/
©2015-2025 Max Guglielmi
? 清除篩選
Product Name DC Spark-over Voltage @100V/S Maximum Impulse Spark-over Voltage @100V/μS Maximum Impulse Spark-over Voltage @1KV/μS Minimum Insulation Resistance Maximum Capacitance @1MHz Arc Voltage @1A Nominal Impulse Discharge Current @8/20μs ±5times Package Data Sheet
SC1812-600CSMD 600V±20% 1100V 1200V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-350CSMD 350V±20% 800V 900V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-470CSMD 470V±20% 900V 1000V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-420CSMD 420V±20% 900V 1000V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-300CSMD 300V±20% 800V 900V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-230CSMD 230V±20% 600V 750V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-200CSMD 200V±20% 600V 750V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-150CSMD 150V±20% 600V 700V 1 GΩ (at 50V DC) 1.0pF 15V 2KA 1812
SC1812-90CSMD 90V±20% 600V 700V 1 GΩ (at 50V DC) 1.0pF 15V 2KA 1812
SC1812-400CSMD+ 420V±20% 900V 1000V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
SC1812-400CSMD 400V±20% 900V 1000V 1 GΩ (at 100V DC) 1.0pF 15V 2KA 1812
